Production process and manufacturing methods of air filter elements

A maintenance equipment for air filter elements and cartridges used in vehicle exhaust

Introduction: A maintenance device for air filter elements and cartridges used in vehicle exhaust of the present technology, including an air filter element and cartridge maintenance machine, the upper side of the air filter element and cartridge maintenance machine is provided with a motor cavity, the motor cavity is provided with a running mechanism for operating the equipment, the running mechanism includes a first motor in the motor cavity, and the first motor is fixed on the upper inner wall of the motor cavity. The first motor is rotatably connected to the first motor shaft. The equipment has a simple structure and is easy to implement. According to the spraying mechanism, it can automatically spray and apply oil to the filter element and filter cartridge with cleaning agent. According to the cleaning mechanism, it can automatically brush off the dirt on the filter element and filter cartridge. According to the flushing mechanism, it can automatically wash away the dirt softened by the cleaning agent. The drying mechanism can automatically dry the filter elements and cartridges after rinsing. The entire process does not require human supervision. It can be manually started, from spraying detergent to scrubbing, rinsing, drying and oiling, all in one step. After maintenance is completed, the machine will automatically shut down. It is highly efficient and has a good cleaning effect.

A cleaning system for automotive air filter elements and its cleaning method

Introduction: This technology provides an automotive air filter element cleaning system and its cleaning method, including a housing. One side of the housing is fixedly connected with a first motor through bolts. The output shaft of the first motor is welded with a rotating shaft. One end of the rotating shaft passes through the housing. The outer side wall of the rotating shaft is fixedly connected with an active roller shaft. The outer side wall of the active roller shaft is fixedly connected with protruding teeth. The outer side wall of the said active roller shaft is connected with four uniformly distributed chains through convex tooth transmission, and the outer side wall of the chains is adhered with trapezoidal protrusions. The staff insert the filter element through the material port onto the surface of the chain, turn on the switch, and the first motor drives the chain to rotate, transporting the filter element. The filter element is cleaned by the cylinder brushes on the surface of the rotating driving and driven rotating rods. The water pump pumps the cleaning liquid from the water tank to the surface of the cylinder brushes and the filter element. The fixed plate and the brush further brush off the flocculent substances inside the filter element. The operation is automated, saving labor. Clean thoroughly.
